| PART NUMBER |
883-06-212 |
| FEATURES |
Performance Tuned For Vehicle Specific Application; Aluminum Body Dissipates Heat Faster Than Steel; External Reservoir System Dissipates Heat Fast; Black Anodized CNC Machined Aluminum Components |
| SERIES |
Performance Elite |
| TRAVEL |
5.47 |
| FRONT LIFT HEIGHT |
4-4.5 |
| BODY |
2.5" Impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time |
| BODY PLATING |
Hard-anodized for a durable finish |
| COMPONENTS |
Black-anodized, CNC-machined 6061-T6 billet aluminum |
| SHAFT |
7/8" hard chrome plated steel shafts |
| VALVING |
Application specific valving to maximize performance |
| SEALS |
Redundant sealing pack system main seal, wiper seal, scraper seal |
| BEARINGS |
PTFE-lined, heat-treated, alloy steel spherical |
| EXTENDED LENGTH |
23.41 |
| COMPRESSED LENGTH |
17.94 |
| TOP MOUNT |
OEM |
| BOTTOM MOUNT |
Bar Pin |
| FITMENT NOTES |
Without Sasquatch Package | Requires Upper Control Arm | Excludes Raptor submodel |
